Description
MaaS or Metal as a service from Canonical is a great way to provision bare metal machines as well as virtual machines. MaaS allows you to deploy Windows, Linux, ESXi, and many other operating systems to your systems helping you to build a bare metal cloud. You can even use Packer from Hashicorp to configure custom images too! We’ll cover all of this and more in this tutorial on how to install and configure MaaS from start to finish with Packer!
Sponsor
New Customer Exclusive - $25 Off ALL Processors: https://micro.center/3si
Check out Micro Center’s Custom PC Builder: https://micro.center/wcx
Submit your build to Micro Center’s Build Showcase: https://micro.center/dcm
Visit Micro Center’s Community Page: https://micro.center/2vr
Installing MaaS
MaaS can be installed via apt
or snap
. I had some issues with the apt
version so I used snap
for this install.
snap install
Be sure snap
is installed
sudo apt install snapd
sudo snap install --channel=3.2 maas
Installing a Test Database
(skip this step if you already have postgres in your environment)
This should be used if you want to use MaaS test database
sudo snap install maas-test-db
testing the database
sudo maas-test-db.psql
then list databases you should see maasdb
there
postgres=# \l
Initializing MaaS
If you are using the test database above, initialize maas
sudo maas init region+rack --database-uri maas-test-db:///
If you already have postgres in your environment you can initialize maas using your existing postgres service. Be sure to create the database, user, and assign that user permissions before running the init command.
sudo maas init region+rack --database-uri "postgres://username:[email protected]/maas" # replace username /password / ip /db name
if you don’t wand to store your secrets in your terminal’s history, consider using ENV variables:
sudo maas init region+rack --database-uri "postgres://$MAAS_DBUSER:$MAAS_DBPASS@$HOSTNAME/$MAAS_DBNAME"
Create admin account
sudo maas createadmin
Here you can choose to import your LaunchPad or GitHub public key using gh:githubusername
Checking MaaS
sudo maas status
The output should like something similar to this:
bind9 RUNNING pid 1014, uptime 2 days, 10:52:40
dhcpd STOPPED Not started
dhcpd6 STOPPED Not started
http RUNNING pid 1477, uptime 2 days, 10:52:23
ntp RUNNING pid 1143, uptime 2 days, 10:52:37
proxy RUNNING pid 1454, uptime 2 days, 10:52:25
rackd RUNNING pid 1017, uptime 2 days, 10:52:40
regiond RUNNING pid 1018, uptime 2 days, 10:52:40
syslog RUNNING pid 1144, uptime 2 days, 10:52:37
If you ever need to reinitialize MaaS
sudo maas init region
Configuring Packer Images
Install Packer
Get key ring
wget --no-verbose --output-document=- https://apt.releases.hashicorp.com/gpg | sudo gpg --dearmor --output=/usr/share/keyrings/hashicorp-archive-keyring.gpg
Add keyring
echo "deb [arch=$(dpkg --print-architecture) signed-by=/usr/share/keyrings/hashicorp-archive-keyring.gpg] https://apt.releases.hashicorp.com $(lsb_release --codename --short) main" | sudo tee /etc/apt/sources.list.d/hashicorp.list
add Hashicorp Repo
sudo apt-add-repository "deb [arch=amd64] https://apt.releases.hashicorp.com $(lsb_release -cs) main"
Install Packer
sudo apt update
sudo apt install packer
Update and install dependencies needed to build images
sudo apt update
sudo apt install qemu-utils qemu-system ovmf cloud-image-utils make curtain git
Building a custom image from canonical/packer-maas
Clone the canonical/packer-maas
repo
git clone https://github.com/canonical/packer-maas.git
cd packer-maas
cd ubuntu
sudo packer init ubuntu-cloudimg.pkr.hcl
sudo make custom-cloudimg.tar.gz
check and change permissions of archive (change root
to your username)
ls -l
sudo chown root:root ./custom-cloudimg.tar.gz
Uploading Packer image to MaaS
echo your maas
api key to your home directory
sudo maas apikey --username=massadmin > ~/api-key-file
You can check with with
cat ~/api-key-fil
Authenticate to maas
with your api key
maas login massadmin http://localhost:5240/MAAS/api/2.0/ $(head -1 ~/api-key-file)
Upload the custom image we made to maas
maas massadmin boot-resources create name='custom/cloudimg-tgz' title='Ubuntu Custom TGZ' architecture='amd64/generic' filetype='tgz' content@=custom-cloudimg.tar.gz
Chapters
00:00 - What is MaaS (Metal as a Service) from Canonical?
02:00 - Micro Center / $25 Off CPUs! (Sponsor)
03:00 - Installing MaaS
06:56 - Initial MaaS Configuration
09:41 - Importing your SSH Key
10:23 - Networking Configuration & Discovery
14:05 - PXE & Network Boot with DHCP
15:33 - Commissioning a Machine (Initial Discovery)
18:45 - Power Types & Wake on LAN (WOL)
20:50 - Commissioning a Machine Part 2 (For real this time)
24:00 - Deploying Ubuntu
26:15 - SSH in to machine
26:54 - Creating Custom Images with Hashicorp Packer
33:40 - Uploading a Custom Image to MaaS
38:40 - What do I think of MaaS from Canonical?
39:57 - Stream Highlight - “100 + 50 subs dropped 🫳🎤”
